Hyva Replacement Telescopic Cylinders



Need a replacement for a Hyva FE, FC, FEE or FSE telescopic cylinder? We manufacture drop-in replacements with identical mounting dimensions, stage diameters and stroke - built from 27SiMn seamless steel tube with hard-chromed rods and Hallite seals. Send us your original part number or a photo of the nameplate, and we will confirm the match within 12 hours.

✓ Same mounting dimensions ✓ Same stroke ✓ 12-month warranty ·




A failed tipping cylinder puts a truck out of service, and every day off the road costs money. Waiting weeks for an original part - and paying the original price - is often not an option. Our replacement cylinders are built to the same dimensional and performance specifications, so they bolt straight onto your existing brackets with no modification.



Drop-in fit, no modification

Identical pin-to-pin closed length, trunnion width, mounting interface and port positions. Your existing brackets and hydraulic connections stay as they are.

Same materials, verified

27SiMn quenched & tempered seamless tube, hard-chrome plated rods (0.015–0.025 mm), Hallite / Kaden / Merkel seal kits. Same grade as the original.

Tested before shipping

Every cylinder passes a 1.5× rated-pressure test, full-stroke cycling and leak testing. Pressure test certificate provided on request.

Drawing supplied before you pay

We send a dimensioned drawing for your approval first. You confirm the fit, then we build. No guesswork.





We manufacture replacements for the following front-end and underbody series:

Hyva series	Description	1st stage bore	Stroke range
FE	Front-end cylinder with piston eye, for slanted headboard	110 – 226 mm	2,785 – 9,030 mm
FE Heavy Duty	Reinforced version, tipping capacity over 100 t	110 – 226 mm	2,785 – 9,030 mm
FC	Front-end cylinder with outer cover	110 – 226 mm	3,100 – 9,530 mm
FC Heavy Duty	For straight headboard, over 100 t	110 – 226 mm	3,100 – 9,530 mm
FEE	Piston eye + bottom eye + pin connection, 250 bar	110 – 226 mm	2,785 – 9,030 mm
FSE	Piston eye + bottom eye, for slanted headboard	110 – 226 mm	2,785 – 9,030 mm



We also build replacements for Custom Hoist, Edbro (CX series), Binotto, Mailhot and Penta telescopic cylinders. If your brand is not listed, send us the specification anyway - we work from drawings as well as part numbers.

Cross reference: Hyva part number → ZHONGXIN model

Our model code follows the same logic as Hyva's: series + first-stage bore (mm) + number of stages + stroke (mm). So FE 169-5-5405 means an FE-series cylinder with a 169 mm first stage, 5 stages and a 5,405 mm stroke. Find your original below, or search by bore and stroke.



Hyva part no.	Stages	Largest stage	Total stroke	Closed length	ZHONGXIN model
70544230	3	129 mm	3,880 mm	1,600 mm	FE 129-3-3880
71534180	3	129 mm	3,460 mm	1,449 mm	FE 129-3-3460
71534220	3	129 mm	3,880 mm	1,609 mm	FE 129-3-3880
70546474	5	169 mm	5,830 mm	1,529 mm	FE 169-5-5830
70547530	5	191 mm	6,230 mm	1,532 mm	FE 191-5-6230
71537490	5	191 mm	6,180 mm	1,527 mm	FE 191-5-6180
71538582	5	214 mm	7,130 mm	1,722 mm	FE 214-5-7130
70548576	6	214 mm	7,000 mm	1,517 mm	FE 214-6-7000



Cross reference is provided as a selection guide. Final confirmation is always based on the drawing we send you before production.







If the nameplate is worn or painted over, these three measurements are enough for us to identify a match:

Largest stage outer diameter - measure the widest tube with callipers

Extended length - pin centre to pin centre, fully extended

Closed length - pin centre to pin centre, fully retracted

Take a photo of the cylinder and of the nameplate if you can find it, and send both. Our engineers deal with this every day and can usually identify the model from photos alone.





Parameter	Specification
First stage bore	80 – 300 mm (customizable)
Maximum stroke	up to 8,000 mm
Number of stages	2 – 8
Rated working pressure	21 – 31.5 MPa (3,000 – 4,500 PSI)
Operating temperature	−20 °C to +120 °C (−4 °F to 248 °F)
Barrel material	27SiMn seamless steel, quenched & tempered
Piston rod	Hard chrome plated 27SiMn, 0.015 – 0.025 mm, Ra ≤ 0.8 μm
Seal kit	Hallite / Kaden / NOK
Mounting	Flange, clevis, eye, trunnion, pin-to-pin, pin-to-trunnion
Acting type	Single acting (standard), double acting (on request)
Surface treatment	Sandblasting, primer, intermediate and finish coat, colour to your specification
Testing	1.5× rated pressure test, full-stroke cycling, fatigue test to 10⁶ cycles
Warranty	12 months from arrival at your port





• Step 1 - Send us your part number or a photo

Use the form on this page, or WhatsApp us directly. A photo of the nameplate is ideal, but measurements are enough.

• Step 2 - We confirm and send a drawing

Within 12 hours you receive a dimensioned drawing plus a quotation. Check the drawing against your old cylinder.

• Step 3 - Production and testing

Typical lead time is [lead time] after drawing approval. Every cylinder is pressure tested before packing, and packed in a plywood case suitable for export.









Send us your part number, measurements or photos - whichever you have to hand. You will get a dimensioned drawing and a quotation within 12 hours, with no obligation.

• WhatsApp: +86 15253927511
• Email: ada@zxhydraulicmaker.com


Send Your Part Number

Trademark notice: Hyva, Custom Hoist, Edbro, Binotto, Mailhot and Penta are registered trademarks of their respective owners and are used here solely to indicate compatibility. ZHONGXIN is an independent manufacturer and is not affiliated with, authorized by, or endorsed by any of these brand owners. All replacement cylinders are manufactured to ZHONGXIN specifications.
